Model: 717-15G
Pressure switch test function captures set, reset and Deadband values of a pressure switch. Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power.
Pressure Calibrator,Multifunction,Source Voltage 24V Loop Power Supply,Voltage Measurement Range No,Source Current No,Current Measurement Range 0 to 24 mA,Accuracy 0.015 Percent,Thermocouple Type No,Thermocouple Temperature Range No,RTD Type No,RTD Temperature Range No,Frequency Source Range No,Frequency Measurement Range No,Resistance Source No,Resistance Measurements No,Supply Pressure (PSI) No,External Pressure Range 29 ranges 0 to 10,000 psi
| Range | 29 pressure modules, 0 – 1 in H20 to 10,000 PSI, 2.5 mbar to 700 bar ranges over pressure per pressure module specs |
| Resolution | Per pressure module specs |
| Accuracy | 0.025 % of full span, per pressure module specs |
| Functions | Zero, Min, Max, Hold, Damp, error calculation |
| Note | Media compatibility per pressure module specs |
Click on a category to view a selection of compatible accessories with the Fluke 717-15G Pressure Calibrator 15 Psig.
