Fluke 719-30G Offers
Forget the Hassle of Hand Pumping
Now you can calibrate and test pressure devices quickly and easily with one hand, saving valuable time. With the innovative, built-in electric pump, the Fluke 719 Electric Pressure Calibrator provides pressure calibration at your fingertips!
Use the programmable pump limit settings to eliminate over-pressurization, and to set ‘pump to' pressure values. The unique cleanout port design reduces pump failures, and makes the 719 easy to clean without repair. The compact, lightweight form, combined with one-handed calibration, makes this pressure calibrator the ideal tool for busy process professionals.
Pressure calibration made easy, by a name you know and trust for all your process calibration needs.
Fluke 719-30G Specifications
| General Specifications |
| Storage temperature | |
| Operating temperature | |
| Relative humidity |
|
95 % (-10 °C to 30 °C) |
|
75 % (30 °C to 40 °C) |
|
45 % (40 °C to 50 °C) |
|
35 % (50 °C to 55 °C) |
|
| Shock | |
| Safety |
|
CSA C22.2 No. 1010.1:1992 |
|
| EMC |
|
EN50082-1:1992 and EN55022:1994 Class B |
|
| Size (HxWxL) |
|
60 mm x 87 mm x 210 mm |
|
(2.19 in x 3.41 in x 8.28 in) |
|
| Weight | |
| Battery |
|
Two 9 V alkaline batteries |
|
| Battery life |
|
12 hours with 12 mA into 500 Ω, 200
pump cycles to 100 psi, 500 pump cycles to 30 psi |
|
| Warranty |
|
Three-years, one year for pump |
|
| Specification |
| Fluke-719 30G |
| Range |
-12 to 36 psi,
-850 mbar to 2.4 bar |
| Resolution |
0.001 psi, 0.1 mbar |
| Accuracy |
0.025 % range for 6
months |
|
0.035 % of range for
one (1) year |
|
| Fluke-719 100G |
| Range |
-12 to 120 psi,
-850 mbar to 8 bar |
| Resolution |
0.01 psi, 1 mbar |
| Accuracy |
0.025 % range for 6
months |
|
0.035 % of range for
one (1) year |
|
| mA |
| Range |
0 to 24 mA |
| Resolution |
0.001 mA |
| Accuracy |
.015 % Rdg + 2 counts |
| Notes |
Max load, 1000 Ω,
750 Ω ohm in HART mode |
|
| Loop supply |
| Range |
24 V dc |
| Resolution |
N/A |
| Accuracy |
± 10 % |
|
| Pump specifications |
| Maximum pressure generation |
|
120 PSI (8 BAR) (100 PSI model) |
|
| Pump to |
|
- 30 PSI in less than 15 seconds* |
|
- 100 psi in less than 45 seconds* |
|
*(with 1 meter of 1/8 inch test hose) |
|
| Pump cycles between rebuilds | |
| Total pump life | |
Click here for complete specifications on the Fluke 719-30G
What's included with the Fluke 719-30G
- TL75 Test leads
- AC72 Alligator clip set
- Push fit connectors
- Translucent test hose
- Product overview manual (print), and
- User's manual (CD-ROM) in 14 languages
