Fluke T6-600 Electrical Tester with FieldSense Technology

Model: T6-600

Measure voltage up to 1000 V AC through the open fork with this electrical tester. It's FieldSense technology which enables users to take AC voltage, current, and frequency measurements without making contact with the live voltage. Additionally, it features a 0.7" (17.8 mm) open fork.

Add In-House ISO Certified Calibration to your Fluke T6-600


$253.80 CAD

was $282.00

Availability:
23 in Stock
Need a quote?




Fluke T6-600 Offers

Features

  • FieldSense technology for ac voltage, current and frequency measurement without making electrical contact to live voltage
  • See voltage or current display - shows all power supply measurements at a glance for efficient trouble shooting
  • True RMS voltage and current
  • Works with wires up to AWG 4/0 (120 mm2) with a 0.7" (17.8 mm) jaw opening
  • HOLD button temporarily freezes the reading for easy viewing
  • Easy to read display with backlight

Tips: FieldSense Technology

Do not hold or touch wire you are testing during a measurement. Use the black probe to make the ground connection if:

  • wearing gloves or insulated footwear
  • standing on an insulated ladder
  • additional ground contact is required for the application

FieldSense measurement looks like this when properly grounded:

  • Display color turns green
  • Display shows a valid measurement >16 V rather than dashes or 0.0
  • Shows for measurement ≥30 V

Why use this electrical tester?

Electricians often work in boxes jammed with wires, where finding a safe metallic contact point can be a challenge. With this unit, you take measurements by sliding a single wire into the open fork.

How FieldSense works

FieldSense technology is truly a breakthrough in how voltage is measured. While other open fork testers detect a magnetic field to show ac current, FieldSense technology detects an electrical field. This field interacts with a reference signal created by the tester, creating a voltage value on the tester's display.

Applications

  • Commercial electricans
  • Light industrial electricians

Fluke T6-600 Specifications

FieldSense AC Voltage True RMS
Requires Test Leads No
Range 600 V
Resolution 1 V
Accuracy ±(3% + 3 counts) 45 to 66 Hz
FieldSense AC Current True RMS
Requires Test Leads No
Range 200.0 A
Resolution 0.1 A
Accuracy ±(3% + 3 counts) 45 to 66 Hz
FieldSense Frequency (Hz)
Requires Test Leads No
Resolution 1 Hz
Accuracy ±(1% + 2 counts)
Volts AC True RMS
Requires Test Leads Yes
Range 600 V
Resolution 1 V
Accuracy ±(1.5% + 2 counts) 45 to 66 Hz
Volts DC
Requires Test Leads Yes
Range 600 V
Resolution 1 V
Accuracy ±(1.5% + 2 counts)
Resistance
Requires Test Leads Yes
Range 2000 Ω
Resolution 1 Ω
Accuracy ±(1.5% + 2 counts)
General Specifications
Calibration 1-year calibration cycle
Jaw Opening 0.7" (17.8 mm)
Operating Temperature 14 to 122°F (-10 to 50°C)
Storage Temperature -22 to 140°F (-30 to 60°C)
Operating Altitude 6562' (2000 m)
Storage Altitude 32,808' (10,000 m)
Relative Humidity 0 to 90% at 41 to 86°F (5 to 30°C)
0 to 75% at 86 to 104°F (30 to 40°C)
0 to 45% at 104 to 122°F (40 to 50°C)
Battery Type and Life 2 x AA Battery (IEC LR6): 360 hours continuous, typical
200 hours using FieldSense
Temperature Coefficient 0.1 x (specified accuracy)/°F <64.4°F or >82.4°F (°C for <18°C or >28°C)
Dimensions 2.4 x 10.2 x 1.7" (61.1 x 259.3 x 43.8 mm)
Weight 0.78 lb (0.35 kg)
Safety IEC/EN 61010-1: Pollution Degree 2
Electromagnetic Environment IEC/EN 61326-1: Portable
Click here for complete specifications on the Fluke T6-600

What's included with the Fluke T6-600

  • Electrical Tester
  • Attached Test Leads, with Removable 4 mm Removable Probe Caps
  • User Documentation

Fluke T6-600 Electrical Tester: Introduction


This video will introduce the key features of this electrical testers. Additionally, this unit also comes with FieldSense Technology.

Introducing the Fluke T6 Electrical Tester


This video gives a brief introduction to the main features on the Fluke T6 like the fact that you can measure voltage and current levels at the same time! Without test leads!

Introducing the Fluke T6 Electrical Tester


This video gives a brief introduction to the main features on the Fluke T6 like the fact that you can measure voltage and current levels at the same time! Without test leads!
